SOLEN BEAM H1Z2Z2-K
Application
Solen H1Z2Z2-K Solar cables conforming to European standard ‘EN 50618’ and international standard ‘IEC 62930’ are designed for installations in photovoltaic systems, solar parks, solar farms, rooftop solar systems and in interconnection of solar panels and inverter. Suitable for fixed installations within pipes or systems, indoor or outdoor solar applications, installations where fire, smoke emissions and toxic fumes pose potential risks to life and equipment.
Conductor: Tinned annealed flexible copper-Class 5 according to IEC 60228
Insulation: Halogen free E-beam cross-linked compound according to EN 50618 Table B.1
Outer Sheath: Halogen free E-beam cross-linked compound according to EN 50618 Table B.1
Sheath Color: Black or Red (Blue and Green-yellow available upon request)
Rated Voltage (U o/U)
AC: 1000 / 1000 V
DC: 1500 V
Max Voltage
AC: 1200 / 1200 V
DC: 1800 V
Test Voltage
6,5 kV AC, 15 kV DC (5 min.)
Operating Ambient Temperature
40°C / +90°C
Max. Temperature at Conductor
+125 °C based on EN 60216-1 (20.000 h, 50% residual elongation)
Installations Temperature
-25°C / +60°C
Short Circuit Temperature
+280°C Max. 5 sec.
Min. Bending Radius
≥ 4 x D as per EN 50565-1
Insulation Resistance
EN 50395 Clause 8.1, IEC 60227-2 Clause 2.4
Surface Resistance of Sheath
EN 50395 Clause 11, IEC 62821 Clause 5.1
Cold Bend Test
EN 60811-504 (-40°C)
Cold Elongation
EN 60811-505 (-40°C)
Cold Impact
EN 60811-506 & EN 50618 (-40°C)
Damp Heat Test
EN 50618 (Table 2), EN 60068-2-78 (1000 hours, 90°C & %85 humidity)
Halogen Free Properties
EN 50525-1 (Annex B), IEC 60754-1, IEC 60754-2
Low Smoke Emission
EN 61034-2 (Light transmittance > 60%)
Flame Retardancy
EN 60332-1-2
Ozone Resistance
IEC 60811-403, EN 50396 Clause 8.1.2
Weather / UV Resistance
EN 50618 (Annex E), IEC 62930
Acid and Alkaline Resistance
EN 50618 (Annex B)
Shrinkage Test
EN 60811-503, IEC 60811-503, EN 50618 (Table 2)
Durability of Print EN 50618
Long Term Resistance of Insulation to DC
EN 50395 Clause 9 IEC 62821-2
Ammonia Resistance
7 days at 230C saturated ammonia atmosphere (internal tested)
Salt Water Resistance
7 days at 230C in saturated salt solution (internal tested)
Water Submersion
AD8 EN 50525-2-21 Appendix E (internal tested)
Underground use
UL 854 Section 23 Impact-renstance test E (internal tested)
UL 854 Section 24 Crushing- renstance test E (internal tested)
| PART NO | NUMBER OF CORES |
CROSS- SECTIONS (mm2) |
CONDUCTOR RESISTANCE (at 20 oC Ω/km) |
CURRENT CARRYING CAPACITY (A) |
SHORT CIRCUIT CURRENT |
||
| Single Cable in Free Air |
Single Cable on Surface |
Two Loaded Cables Touching On a Surface |
(5s. from 90 oC to 280 oC) kA |
||||
| SEB50015CL000 | 1 | 1,5 | 13,7 | 40 | 35 | 29 | 0,10 |
| SEB50025CL000 | 1 | 2,5 | 8,21 | 54 | 47 | 40 | 0,17 |
| SEB50040CL000 | 1 | 4 | 5,09 | 71 | 63 | 53 | 0,27 |
| SEB50060CL000 | 1 | 6 | 3,39 | 90 | 80 | 68 | 0,41 |
| SEB50100CL000 | 1 | 10 | 1,95 | 126 | 113 | 96 | 0,69 |
| SEB50160CL000 | 1 | 16 | 1,24 | 169 | 153 | 130 | 1,10 |
| SEB50250CL000 | 1 | 25 | 0,795 | 225 | 204 | 173 | 1,72 |
TÜV RHEINLAND approved product certificateREACH and RoHS ComplaintCPR rating Dca acc. to EN 50575 (Cca upon request)Expected service lifetime (Min. 35 years acc. to EN 50618)Higher insulation resistanceHigh current carrying capacityCompatible for all major connectorsAG2 Medium severity impact resistanceAD8 water submersion compatibleAmmonia ResistanceSalt Water ResistanceSuitable for and wet, damp and humid locationsExcellent flexibilityGood stripping performance from conductorAbrasion resistantUV, Oil, Grease and Ozone resistantAcid and Alkaline resistantAnti rodent and Anti termite versions are available.Direct BurialDo not Contain Fish Oil
DIRECT BURIAL CONDITIONS:
Allowed to be direct burial to earth that does not contain any damaging chemicals, solvents, rodents, termites etc. Correct installation methods based on VDE 0800-174 and VDE 0891-6 have to be applied and necessary cautions should be taken to avoid physical damage of cables during installation. Burial in pipes/conduits/channels will give you better and safer installation.
